Description:

Origin: Mainland China
Type: Oil Pressure sensor
Sensitivity: ≤±1.0%FS
Measuring Range: 0-300psi
OEM NO.: 0-300psi
Style: Varistor Type
Signal Type: Voltage Signal
Supply voltage: 5VDC or 12VDC or 3.3VDC
Sensor core: ceramic sensor
Pressure connection: 1/8NPT or other
Protection class: IP65
Electromagnetism Compatibility: EN50051-1
Max Measuring Range: 59 Bar & Under
Measuring range: -14.5-30psi / 5-300psi gauge pressuure
Output signal: 0.5-4.5V or 0-5V or 1-5V or 0.4-2.4V(Low power consumption)
Operating temperature: -40-105℃
Housing material: 304 Stainless Steel
Electrical connection: Packard connection
Explosion-proof class: Exia2CT6
Choice: yes
semi_Choice: yes

Features:

• Its an advance pressure transducer than traditional mechanical pressure transducer.

• ±2%FS small output error, including nonlinear, hysteresis error and repeatability, full temperature range.

• Light weight and small size, convenient to install and operate.

• It has complete surge voltage protection function.

• Works for oil, fuel, diesel, gas, water, air pressure, can be used in oil tank, gas tank, diesel tank etc.

Specifications:

Material: Stainless steel

Voltage: DC 5V

Pressure: 30 psi, 100 psi, 150 psi, 200 psi, 300 psi, 500 psi (Optional)

Thread Type: 1/8" NPT

Parameters

Measuring range: -14.5-30psi / 5-300psi gauge
pressure
Accuracy: ±1.0%FS
Output signal: 0.5-4.5V, 0-5V, 1-5V
Supply voltage: 5VDC, 12VDC, 3.3VDC
Operating temperature: -40～105℃
Compensation temperature: -20～80℃
Operating current: ≤3mA
Temperature drift (zero&sensitivity): ≤±0.03%FS/℃
Long-term stability: ≤±0.2%FS/year
Response time: ≤3ms
Overload pressure: 150%FS
Burst pressure: 300%FS
Cycle life: 500,000 times
Sensor core: Al2O3-96% ceramic sensor
Pressure medium: Non-corrosive liquid or gas
Pressure connection: 1/8”NPT, Other pressure connection is on request
Electrical connection: Packard connection
Housing material: 304 Stainless Steel
Protection class: IP65
Explosion-proof class: ExiaⅡCT6
Weight: ≈0.080kg
